Figure 9 shows air trapped in a vertical cylinder by a valve and a piston P - AQA - A-Level Physics - Question 4 - 2022 - Paper 3
Question 4
Figure 9 shows air trapped in a vertical cylinder by a valve and a piston P. The valve remains closed throughout the experiment. A mass is placed on top of P. P mov... show full transcript
Worked Solution & Example Answer:Figure 9 shows air trapped in a vertical cylinder by a valve and a piston P - AQA - A-Level Physics - Question 4 - 2022 - Paper 3
Step 1
Show that y is not inversely proportional to M.
Answer
To show that y is not inversely proportional to M, we can analyze the data provided in Figure 10. The relationship between y and M can be examined by calculating the ratio of y to M for different points.
-
Collect Data Points: Take the data points from Figure 10 for M (mass in kg) and y (distance in mm).
-
Calculating Ratios: For each data point, calculate the values of y/M. If y were inversely proportional to M, we would expect this ratio to be constant.
-
Evaluate Results: Plot the calculated ratios and observe if they remain consistent. If there is a variation, it proves that y is not inversely proportional to M.
-
Conclusion: Since the ratios are not constant, we can conclude that the relationship between y and M does not support an inverse proportionality.
