Ammonium nitrate is a commonly used fertiliser - Scottish Highers Chemistry - Question 6 - 2023
Question 6
Ammonium nitrate is a commonly used fertiliser.
(a) (i)
Ammonium nitrate is made industrially by adding nitric acid, HNO₃, to ammonia, NH₃.
HNO₃(aq) + NH₃(g) ⇌ NH... show full transcript
Worked Solution & Example Answer:Ammonium nitrate is a commonly used fertiliser - Scottish Highers Chemistry - Question 6 - 2023
Step 1
Complete the diagram to show the shape of the enthalpy diagram for this reaction.
96%
114 rated
Only available for registered users.
Sign up now to view full answer, or log in if you already have an account!
Answer
The enthalpy diagram should show a curve that starts at the energy level of the reactants and rises up to a peak at the activation energy (X), then falls down to a lower energy level at the products. This represents an exothermic reaction where the products have lower potential energy than the reactants.
Step 2
State the term for the unstable arrangement of atoms formed at the point labeled X on the potential energy diagram above.
99%
104 rated
Only available for registered users.
Sign up now to view full answer, or log in if you already have an account!
Answer
Activated complex.
Step 3
Suggest a reason why the method shown in part (a)(ii) is the preferred industrial route.
96%
101 rated
Only available for registered users.
Sign up now to view full answer, or log in if you already have an account!
Answer
The method has 100% atom economy and produces only one product, making it more efficient and cost-effective than alternative methods.
Step 4
Suggest what is represented by the area under the curve in Graph 1.
98%
120 rated
Only available for registered users.
Sign up now to view full answer, or log in if you already have an account!
Answer
The area under the curve in Graph 1 represents the total number of molecules or particles in the gas mixture.
Step 5
Add a second curve to Graph 1 to show the distribution of kinetic energies at a higher temperature.
97%
117 rated
Only available for registered users.
Sign up now to view full answer, or log in if you already have an account!
Answer
The second curve should be displaced to the right of the original curve, indicating that at a higher temperature, there are more molecules with greater kinetic energy.
Step 6
Draw a line to show how a catalyst affects the activation energy, EⱣ.
97%
121 rated
Only available for registered users.
Sign up now to view full answer, or log in if you already have an account!
Answer
Draw a vertical line at a lower kinetic energy than the original EⱣ, indicating that a catalyst lowers the activation energy required for the reaction.
Step 7
State what is meant by the term dynamic equilibrium.
96%
114 rated
Only available for registered users.
Sign up now to view full answer, or log in if you already have an account!
Answer
Dynamic equilibrium occurs in a reversible reaction when the rate of the forward reaction equals the rate of the reverse reaction, and the concentrations of reactants and products remain constant.
Step 8
Explain how this will affect the production of ammonia.
99%
104 rated
Only available for registered users.
Sign up now to view full answer, or log in if you already have an account!
Answer
Removing ammonia continuously will shift the equilibrium to the right, according to Le Chatelier's principle, increasing the yield of ammonia produced.
Step 9
State another way that the manufacturing process maximises profit or minimises the impact on the environment.
96%
101 rated
Only available for registered users.
Sign up now to view full answer, or log in if you already have an account!
Answer
Recycling unreacted gases or using a catalyst can reduce costs and minimize environmental impact in the Haber process.
Step 10
Write the overall redox equation for the reaction taking place in the fuel cell.
98%
120 rated
Only available for registered users.
Sign up now to view full answer, or log in if you already have an account!
Answer
The overall redox equation is:
ightarrow N_2 + 6H_2O$$
Step 11
Identify the reducing agent in the reaction taking place in the fuel cell.
97%
117 rated
Only available for registered users.
Sign up now to view full answer, or log in if you already have an account!
Answer
Ammonia (NH₃) is the reducing agent in the reaction.
