Two variables, x and y, are connected by the equation y = ab^x - Scottish Highers Maths - Question 12 - 2019

Question icon

Question 12

Two-variables,-x-and-y,-are-connected-by-the-equation-y-=-ab^x-Scottish Highers Maths-Question 12-2019.png

Two variables, x and y, are connected by the equation y = ab^x. The graph of log2 y against x is a straight line as shown. Find the values of a and b.

Worked Solution & Example Answer:Two variables, x and y, are connected by the equation y = ab^x - Scottish Highers Maths - Question 12 - 2019

Step 1

State linear equation

96%

114 rated

Answer

From the given equation, we can take the logarithm base 2 of both sides. This gives us:

extlog2y=extlog2(abx) ext{log}_2 y = ext{log}_2(ab^x)

Using the laws of logarithms, this can be expanded to:

extlog2y=extlog2a+ximesextlog2b ext{log}_2 y = ext{log}_2 a + x imes ext{log}_2 b

This indicates that log2 y plotted against x is a straight line, where:

  • The intercept is extlog2a ext{log}_2 a
  • The gradient is extlog2b ext{log}_2 b

Step 2

Interpret intercept

99%

104 rated

Answer

From the graph, we note that when x = 0, log2 y = -1. Therefore, substituting into our equation:

ext{log}_2 a = -1 \\ a = 2^{-1} = rac{1}{2}

Step 3

Interpret gradient

96%

101 rated

Answer

The gradient from the graph is also observed to be 3. Thus, we can state:

extlog2b=3b=23=8 ext{log}_2 b = 3 \\ b = 2^3 = 8

Step 4

State a and b

98%

120 rated

Answer

Finally, we can conclude that:

  • The value of a is rac{1}{2}.
  • The value of b is 8.
